Schottky
MB0560LR
Schottky rectifier
Schottky rectifier in a TO-277B package. Provides low forward-voltage drop and fast switching for high-efficiency rectification and power-supply applications.
TO-277B RoHS Halogen Free AVAILABLE
Package — TO-277B
Features
- Ultrafast reverse recovery time
- Low leakage current
- Low switching losses, high efficiency
- High forward surge capability
- Telecommunication
Applications
- High frequency rectification
- Freewheeling application in switching mode
- converters and inverters for consumer
- Computers
Key specifications
Product Name
MB0560LR
Package
TO-277B
IF
(mA)
5000
IFSM
(A)
240
VRRM
(V)
600
VF@ IF= 1mA
(V)
-
VF@IF=MAX
(V)
1.2
IR
(mA)
0.005
Trr
(ns)
51
Cj
(pF)
52
VRMS
(V)
424
